DYD533

Parameter

Features

• Ideal choices for residential, community, and commercial AC EV charger

• Optional wired/wireless connection for back office management

• Optional RFID card reader for user identification and management

• Input: 200Vac~240Vac

• IP54 rated for indoor/outdoor applications

• Firmware updates through remote connection

• Charging interface: SAE J1772 (Type 1) / IEC 62196-2 (Type2)

Applications

• Highway gas / service station

• Parking garage

• Home use or commercial use

• EV infrastructure operators and service providers

• EV dealer workshops

Features

Category		DYD533 Series
Model Name		DYD533 (EU)	DYD533 (US)
AC Input	Input Rating	230 Vac / Single Phase	315-240 Vac / 1-phase (AC Level 2)
	AC Input Connection	L/N/PE
	Max. Input Current (A)	32
	Frequency (Hz)	45-65
	Residual Current Device(Type B Optional)	Type A: lΔn 30 mA Type B: lΔn 30 mA + dc 6 m	CCID 20
User Interface & Control	Display	3.5 inch LCD
	User Authentication	RFID ISO/IEC 14443A/B
	Display Information	Current, Energy
Communication	External	Ethernet/4G/3G
	Internal	OCPP 1.6 JSON
Environmental	Operating Temperature (°C)	-30 ~ 50
	Humidity (%)	5 ~ 95 RH non-condensing
	Altitude (m)	≤2500m
	IP Level	IP54	NEMA TYPE 3R
	Cooling method	Natural Cooling
Mechanica	Dimension(WxDxH mm)	2501511451
	Weight(kg)	≤10.2
	Cable Length(m)	5
Protection	Input Protection	OCP:<35.2a ovp:=>275V / UVP:<160V
	Output Protection	OCP:<35.2a ovp:=>275V / UVP:<160V
	Ground Fault Protection	Lost input ground connection
Regulation	Certificate	IEC 61851-1:2017 IEC 61851-21-2	UL2594 , UL2231-1/-2
	Safety	CE	UL/cUL
	Charging Interface	IEC 62196-2:2016, Type 2 Plug	SAEJ1772 Type 1 Plug
